Cable TypesIndoor patch cord is current normal one. it is used to attach one device to another for signal routing. Application: ●CCTV●Data transmission.●Telecommunication,●Testing equipment.●WBN,●Optical fiber CATV,●LAN indoor/outdoor. Feature: ●PC UPC APC polishing optional●High credibility and stability●Low insertion loss, high return loss●400X microscope inspecting.●Good in repeatability and exchangeability Singlemode or Multimode fiber optional Fiber optic patch…

What is Armored Fiber Optic Cable?Armored fiber optic cable can be divided into two types according to the metal tube: interlock armored fiber cable and corrugated armored cable. Interlocking armor is an aluminum armor that is helically wrapped around the cable and found in indoor and indoor/outdoor cables. It offers ruggedness and superior crush resistance.…

What Is Fiber Optic Microcables?As fiber optic communications systems are expanded to accommodate rapidly growing communications needs, three has been a demand for higher density cables with higher fiber count. This has led to two new cable designs, microcables with up to 288 or even 432 fibers and high fiber count cables. High fiber counts…

FTTH, or Fiber To The Home, refers to fiber optic cable that replaces the standard copper wire of the local Telco. Many people prefer it because it can carry high-speed broadband services integrating voice, data and video, and runs directly to the junction box at a home or building. For this reason, it is sometimes…

Different Types of PLC Splitters Fiber optic PLC splitter can be categorized by the PLC splitter chip they use, meaning there are 1xN and 2xN PLC splitters, such as 1×4, 1×8, 1×16, 2×32, 2×64, etc. Installers can choose different input and output numbers depending on subscriber conditions or cable length. In addition, PLC splitter manufacturers…

Fiber optic adapters (also called couplers) are designed to connect two fiber optic cables together. They come in versions to connect single fibers together (simplex), two fibers together (duplex), or sometimes four fibers together (quad). Adapters are designed for multimode or singlemode cables. The singlemode adapters offer more precise alignment of the tips of the…

☞Insertion Loss & Back Reflection ●To improve cable performance, Insertion loss and back reflection must be minimized. ●To minimize insertion loss, the proper selection of materials is vital. When pick out the material of the core, we use zirconia ceramic ferrule to reach the optimum insertion loss and return loss. Also, safe termination practices are…

In terms of the cable construction, OS1 is tight buffered while OS2 is loose tube. This determines they’ll be applied in different environment. OS1 single mode fiber is usually deployed in indoor applications such as schools, telecom exchanges and data center while OS2 single mode fiber is more appropriate for outdoor and universal loose tube…

IEC/ISO ITU-T TIA Fiber Standard as below

Fiber optic Attenuator or An optical attenuator, or fiber optic attenuator, is a device used to reduce the power level of an optical signal, either in free space or in an optical fiber. The basic types of optical attenuators are fixed, step-wise variable, and continuously variable. Fiber optic attenuators are devices which reduce (attenuate) the…
