Model Number: double sheath
Place of Origin: Changsha, China
Brand Name: Feiboer
Use: Telecommunication
Warranty Time: 30 years
Products: Double Sheathed Optical Drop Cable
Application: Telecommunication
Fiber core: 1FO, 2FO, 4FO
Color: White, Black
Fiber Type: G657A1, G657A2
Outer Sheath Material: HDPE Black
Inner Sheath Material: LSZH-FR White
Cable Reinforcement: Aramid yarns
Operating Temp: -40 to +85 degree
Certification: CE/ROHS/ISO9001

Product Description
is a multi-purpose cable solutionenabling simple, fast and reliable outdoor-indoortransitions.
With a rugged and watertight construction, the GJYFJY LM4 drop cable suits for aerial installations (spans up to70m). The dimensions of the GJYFJY LM4 drop cable havebeed reduced for better wind behavior performancesand a compatibility with duct installation on severalhundred of meters.
Offering a double sheathed construction, the GJYFJY LM4 drop cable presents two ripcords enabling to strip offits HDPE outer sheath in a couple of seconds. Thanksto this operation a Low Smoke Zero Halogen FlameRetardant LM1L drop cable can be then used forindoor applications.
No splice is thus required to make the transitionbetween the outdoor optical drop and the indoor one.The GJYFJY LM4 enablesthe transmission of optical signalfroman outdoor distribution point to a telecommunicationsoutlet without weighing down the optical budget.

FEATURES & BENEFITS
*Reduced dimensions for improved FTTH roll-outs.
*Enables simple,fast and reliable outdoor-indoortransitions. *One drop for aerial, façade, duct and indoor FTTH roll-outs. *Wide operating temperature range.
*High mechanical performances.
*Integrated in a comprehensive FTTH solution including aerial & façade hardware and transition box,customer terminal box，fibredistribution box and optical telecommunications outlets

TECHNICAL CHARACTERISTICS
Fibre type: Compliant with G657A2 ITUrecommendations
Fibre cores: 1FO, 2FO and 4FO
Buffer: 900um tube
Outer diameter:5mm
Weight: 21kg/km & 22kg/km
Outer sheath material : HDPE Black RAL 9O05
Inner sheath material : LSZH-FR White RAL 9010
Cable reinforcement: Aramid yarns & 2 FRP cores

PERFORMANCES
Maximum Allowable Tension: (IEC 60794-1-2-Method E1) – 800N
Static bending: (IEC 60794-1-2-Method E11)-R min_50mm
Kink
I: (EC 60794-1-2-Method E10)–R min_25mm
Cmush:
(IEC 60794-1-2-Method E3)-200N/cm (Δa≤ 0.1dB)-reversibility at 300N/cm
Temperature Cycling(
IEC 60794-1-2-Method F1)- Δa ≤ 0.1dB/km, reversible between .40’C and +70°C(1550nm) (operation)
Aareversible between -40’C and +70’C(1550 nm) (storage)
Fire behaviour (inner cable)
:(EN 50575)-Dca-S2, d1, a1
